Features
Self-tapping barbed inlet for easy installation
Spiral flow through a large-flow-path water passage reduces likelihood of clogging
Twist-open top with lock for secure operation under pressure and for easy cleaning
Durable high-impact plastic
Resistant to chemicals and fertilizers used in landscape application
Constructed of UV-resistant, durable plastic material to withstand the most adverse conditions
Product Specifications
Operating pressure range: 10 to 24 PSI
Recommended operating pressure: 25 PSI
Filter requirement: minimum of 150 mesh
Material: body and cover of polypropylene
Performance Data
Flow rate in gallons per hour at 5 to 30 psl
|
Color |
5PSI |
10PSI |
15PSI |
20PSI |
25PSI |
30PSI |
|
Red |
1.72 |
2.81 |
3.61 |
4.29 |
4.92 |
5.51 |
*The normal flow rate is 4GPH
Maximum number of 4 GPH red drip emitters on 1/2″ drip tubing with .600lD
|
Drip emitters spacing |
1’ |
2’ |
3’ |
4’ |
|
Flow rate @ 25 PSI |
4.29 |
4.29 |
4.29 |
4.29 |
|
Maximum length |
59 |
94 |
120 |
148 |
|
Flow rate in GPM |
4.22 |
3.36 |
2.86 |
2.65 |
|
Flow rate in GPH |
253.1 |
201.6 |
171.6 |
158.7 |
|
# of drip emitters |
59 |
47 |
40 |
37 |
|
Velocity (f/s) |
4.79 |
3.81 |
3.25 |
3.01 |
|
Total head loss in PSl |
5.1 |
5.38 |
5.02 |
5.31 |
*Based on around 90% flow uniformity and 0% slop
