Models
2W electrical parameter & max cable length
|
Solenoid valve type |
Cable color |
Watt |
Inrush current |
Holding current |
Coil resistance |
|
2W-24VAC |
red/red |
1.7 |
0.25 |
0.125 |
37.5 |
|
2W-24VDC |
black/black |
3.6 |
0.18 |
0.18 |
156 |
|
2W-12VDC |
blue/blue |
4.0 |
0.33 |
0.33 |
36 |
|
2W-9VDC |
red/blue |
4.3 |
0.33 |
0.33 |
36 |
|
Solenoid valve type |
Cable color |
Coil inductance |
Pulse width |
Coil resistance |
|
2W-9-30VDC Pulse |
red/black |
12mH |
20-500mSec |
6 |
3W electrical parameter & max cable length
|
Solenoid valve type |
Cable color |
Watt |
Inrush current |
Holding current |
Coil resistance |
|
3W-24VAC |
red/red |
2.2 |
0.13 |
0.13 |
37.5 |
|
3W-24VDC |
black/black |
4.3 |
0.12 |
0.12 |
137 |
|
3W-12VDC |
blue/blue |
4.3 |
0.28 |
0.28 |
34 |
|
3W-9VDC |
red/blue |
4.3 |
0.47 |
0.47 |
19 |
|
Solenoid valve type |
Cable color |
Coil inductance |
Pulse width |
Coil resistance |
|
3W-9-30VDC Pulse |
red/black |
12mH |
20-500mSec |
6 |
Features
The solenoid actuator is the key part of the valve controller and the important device to connect the valve and controller. The solenoid actuator is compatible with all major controller, can achieve a variety of functions.
